SERVICE PROCEDURES REQUIRING MINOR DISASSEMBLY SERVICE MANUAL NUMBER 28
Page 4A-2 90-863160 MAY 2000
Bravo Transom Assembly Specifications
Torque Specifications
Description lb-in. lb-ft
Nm
Shift Cable Core Wire Anchor Screws 20 2.3
Hose Clamps 35 4
Trim Wire Retainer Screw 95 11
Hinge Pins 150 203
Through Bolt Locknut 25 34
Steering Arm Locknut 50 68
Pivot Bolt 23 30
U-bolt Nuts 53 72
Sterndrive Attaching Nut 23 30
Bell Housing Studs 50 68
Rear Engine Mount Attaching Bolts 37 50
Lubricants / Sealants / Adhesives
Description Part Number
3M Brand Adhesive 92-86166-1
Liquid Neoprene 92-25711-2
Resiweld Sealer 92-65150-1
Quicksilver High Performance Gear Lube 92-816026A4
Loctite 271 92-809820
Quicksilver 2-4-C Marine Lubricant with Teflon 92-825407A12
Quicksilver U-Joint and Gimbal Bearing
Grease
92-828052A2
Super Glue Obtain Locally
Perfect Seal 92-34227-1
Tools
Description Part Number
Bearing Removal and Installation Tool 91-31229A7
Bellows Expander Tool 91-45497A1
Slide Hammer Puller 91-34569A1
Tapered Insert Tool 91-43579
Core Wire Locating Tool 91-17263
Shift Cable Anchor Adjustment Tool 91-17262
Sleeve Removal Tool (U-joint Bellows) 91-862546
Sleeve Installation Tool (U-joint Bellows) 91-818162
Hinge Pin Tool 91-78310
