Connecting The Clevis
1. Lubricate clevis pin and clevis with Special Lubricant 101.
2. Connect clevis to steering lever. Be sure to spread both ends of cotter pin.
IMPORTANT: Ensure that the clevis is positioned as shown below. The angled notch
in the clevis must face the rear.
76087
c
b
c
a
b
a-Clevis
b-Clevis Pin and Cotter Pin
c-Steering Lever
