SERVICE PROCEDURES REQUIRING MAJOR DISASSEMBLY SERVICE MANUAL NUMBER 28
Page 4B-2 90-863160 MAY 2000
Bravo Transom Assembly Specifications
Torque Specifications
DESCRIPTION lb-in. lb-ft Nm
Shift Cable Core Wire Anchor Screws 20 2.3
Hose Clamps 35 4
Trim Wire Clamp 95 11
Hinge Pins 150 203
Bell Housing Studs
Steering Arm Nut
50 68
Rear Engine Mounting Bolt 37 50
U-Bolt Nuts 53 72
Transom Stud Locknut 25 34
Pivot Bolt
Sterndrive Attaching Nut
23 30
Lubricants / Sealants / Adhesives
DESCRIPTION PART NUMBER
3M Brand Adhesive 92-86166-Q1
Liquid Neoprene 92-25711-3
Resiweld Sealer 92-65150-1
Loctite 271 92-809820
Quicksilver 2-4-C Marine Lubricant with Teflon 92-825407A12
Special Tools
DESCRIPTION PART NUMBER
Bearing Removal and Installation Tool 91-31229A7
Bellows Expander Tool 91-45497A1
Slide Hammer Puller 91-34569A1
Tapered Insert Tool 91-43579
Core Wire Locating 91-17263
Shift Cable Anchor Adjustment Tool 91-17262
Sleeve Removal Tool (U-joint Bellows) 91-862546
Sleeve Installation Tool (U-joint Bellows) 91-818162
Hinge Pin Puller (High Performance
Transom Assembly)
91-63616T
