OILDYNE TRIM PUMP

SERVICE MANUAL NUMBER 28

90-863160 MAY 2000 Page 5A-11

Trim Pump Hydraulic System

73552

1-Poppet Valves

2-Pump Adaptor

3-OUT/UP Pressure Relief Valve

4-Thermal Relief Valve

5-Fitting

6-IN/DOWN Pressure Relief Valve
