Mercury BRAVO Service Manual

BRAVO THREE GEAR HOUSING SERVICE MANUAL NUMBER 28
Page 3D-20 90-863160 MAY 2000
Disassembly
1. Remove inner propeller shaft and thrust bearing from assembly.
72255
a
b
a-Inner Propeller Shaft
b-Thrust Bearing
2. Remove bearing cup from outer propeller shaft.
72256
b
a
a-Bearing Cup
b-Outer Propeller Shaft
3. Remove thrust cap using a punch and hammer. Align punch with opening in snap-ring.
72212
71799
a
c
b
a-Thrust Cap
b-Outer Propeller Shaft
c-Shim
