Mercury BRAVO Service Manual

MAINTENANCE
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 1B-7
Tie Bar Pivot Points
MODELS WITH CONTROL VALVE MOUNTED ON STARBOARD TRANSOM ASSEMBLY
22079
22079
a
a
Starboard Engine Port Engine
a-Pivot Point
MODELS WITH CONTROL VALVE MOUNTED ON PORT TRANSOM ASSEMBLY
22079
22079
a
a
Starboard Engine Port Engine
a-Pivot Point
Transom Gimbal Housing Assembly Swivel Shaft and Gimbal Bearing
50072
b
a-Gimbal Bearing Grease Fitting
