Mercury BRAVO

DRIVE SHAFT HOUSING SERVICE MANUAL NUMBER 28
Page 3A-8 90-863160 MAY 2000
Standard Bravo U-joint Assembly
73364
B
A
C
C
A
C
D
10
11
12
13
14
15
16
17
18
19
1
2
3
4
5
6
7
8
9
1
16
1-Locknut
2-Washer
3-Pinion Gear
4-Bearing (Smaller OD)
5-Bearing (Smaller ID)
6-Spacer
7-Bearing Cup (Larger ID)
8-Bearing Larger OD)
9-Sealing Ring
10 - O-Ring
11 - Beveled Washer
12 - Oil Seal
13 - Oil Seal Carrier
14 - Ring Nut
15 - Yoke
16 - Cross and Bearing
17 - Socket
18 - Yoke
19 - O-rings (3)
A
- Quicksilver High Performance Gear Lube
B
- Quicksilver Special Lubricant 101
C
- Quicksilver U-joint and Gimbal Bearing Grease
D
- Engine Coupler Spline Grease
