REMOVAL, INSTALLATION AND ADJUSTMENTS SERVICE MANUAL NUMBER 28
Page 2A-22 90-863160 MAY 2000
Sterndrive Unit Installation
1. Install and align the engine. Refer to the appropriate engine service manual.
NOTE: If the engine was removed and the shift cable was disconnected, reinstall and adjust
the shift cable before proceeding.
2. Place the remote control shift lever in the neutral position.
3. Lubricate the bell housing studs with Quicksilver 2-4-C Marine Lubricant with Teflon.
a
a
76674
a-Bell Housing Studs
4. Lubricate the U-joint shaft splines and the O-rings with Quicksilver Engine Coupler
Spline Grease.
22026
a
b
a-U-Joint Shaft Splines
b-U-Joint Shaft O-Rings
To Next Page
