REMOVAL, INSTALLATION AND ADJUSTMENTS
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 2A-23
IMPORTANT: The edge of the U-joint bellows acts as a seal between the bell housing
and the drive shaft housing. Ensure that the surface is not damaged.
24725
a
a-Drive Shaft Bellows Edge
5. Inspect the U-joint bellows for cracks, nicks, and cleanliness. Replace or clean the
bellows as necessary.
6. Lubricate the O-ring seals on the face of the drive shaft housing.
22031
a
a-O-Ring Seals
To Next Page
