CORROSION PROTECTION - ALL MODELS
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 7A-5
Trim Cylinder Anodes
CAUTION
DO NOT paint new trim cylinder anodes, as this will render them ineffective as a gal-
vanic corrosion inhibitor.
1. Remove screws that secure anodes to trim cylinders. Remove anodes.
71966
a
b
a-Screws
b-Trim Cylinder Anodes
2. Scrape mounting surface on cylinder end cap down to bare metal.
3. Install new anodes and tighten securely.
