BRAVO ONE GEAR HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3B-23
Bearing Carrier Inspection
1. The condition of the propeller shaft tapered roller bearing cup is an indication of the
condition of tapered roller bearing on propeller shaft. Replace bearing and cup if cup is
pitted, grooved, scored, worn, uneven, discolored from overheating or has embedded
metal particles.
2. Check bearing carrier for signs of corrosion, especially on gear housing to bearing
carrier mating surfaces. If corrosion is evident, replace bearing carrier.
Bearing Carrier Disassembly
1. Remove bearing cup using slide hammer puller.
22087
a
b
a-Slide Hammer Puller
b-Bearing Cup
2. Remove oil seals from bearing carrier using a hammer and punch.
22111
a
b
a-Oil Seals (2)
b-Punch
