OILDYNE TRIM PUMP

SERVICE MANUAL NUMBER 28

90-863160 MAY 2000 Page 5A-27

Filter Replacement

1. Remove the filters by twisting while pulling upward.

76887

a-Filters (2)

2. Install new filters.

76888

a-Filters (2)

b-5/8 in. Socket
