BRAVO TWO GEAR HOUSING SERVICE MANUAL NUMBER 28
Page 3C-16 90-863160 MAY 2000
Pinion Bearing Removal
IMPORTANT: All needle bearings MUST BE in place inside bearing casing while driv-
ing pinion bearing from gear case or bearing casing will bend or break and become
difficult to remove.
1. Heat area around bearing remover to approximately 200° F (93.3_C) to ease removal.
Do not use open flame. Remove pinion bearing using bearing remover and driver rod.
Use bearing driver as a pilot.
75902
a
b
d
c
a-Bearing Driver (91-813653)
b-Driver Rod (91-37323)
c-Bearing Remover (91-63638)
d-Area Around Pinion Bearing
