OILDYNE TRIM PUMP SERVICE MANUAL NUMBER 28
Page 5A-4 90-863160 MAY 2000
Maintaining Power Trim Pump Oil Level
CAUTION
Avoid pump damage. Vent reservoir pressure by backing out the vent screw two
turns after tightening completely. Units without a vent screw have a vented fill cap.
Remove the fill neck seal on models without a vent screw.
IMPORTANT: Check the oil level with the sterndrive unit in the full down position.
IMPORTANT: If quicksilver Power Trim and steering fluid is not available, SAE 10W-30
or 10W-40 engine oil can be used in the system.
1. Raise and lower the sterndrive unit 6 to 10 times to purge air from the system. Check
the oil level visually.
2. Maintain the oil level between the “Max” and “Min” marks on the side of the reservoir.
Fill to the bottom lip on the fill neck.
22031
b
a
a-Bottom Lip On The Fill Neck
b-Vented Cap
