COMPACT HYDRAULIC STEERING SERVICE MANUAL NUMBER 28
90-863160 MAY 2000Page 6B-2
Important Information About Thru-Transom Exhaust
This Hydraulic Steering system is not designed for use with Through-Transom exhaust sys-
tems. Do not use this Hydraulic Steering System with a Through-Transom Exhaust System.
Torque Specifications
DESCRIPTION lb-in. lb-ft Nm
Steering Hydraulic Hose Fittings 130 15
Steering System (Pivot Bolts) 25 34
Steering Wheel Shaft Nut
1
150 17
Helm Nuts 110 12
1
: Amount specified is MINIMUM. Do not exceed 200 lb-in. (22 Nm).
Lubricants / Sealants / Adhesives
Description Part Number
Quicksilver 2-4-C Marine Lubricant with Teflon 92-825407A1
Loctite 567 PST Pipe Sealant 92-809822
Quicksilver Hydraulic Fluid, 64-826485A1
Texaco H015 92-862014A1
SeaStar Hydraulic Fluid HA5430
Approved Hydraulic
Chevron Aviation Fluid A
Steering Fluids
Mobil Aero HFA
Obtain Locally
Shell Aero 4
Fluid meeting MIL Specification H5606C
WARNING
Avoid serious bodily injury or death due to loss of steering control. Any
non-approved fluid used in this system may cause irreparable damage, loss of
steering, and cancellation of warranty. Never use brake fluid in this hydraulic
steering system. Use only approved hydraulic fluids.
