BRAVO ONE GEAR HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3B-13
Gear Housing Disassembly
1. Remove propeller.
75492
c
b
a
d
f
e
a-Forward Thrust Hub
b-Flo-Torque Drive Hub
c-Propeller
d-Drive Sleeve Adaptor
e-Tab Washer
f-Nut
2. Bend tabs of tab washer away from bearing carrier retainer nut.
50136
a
b
a-Tab
b-Screw Driver
