DRIVE SHAFT HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3A-15
b. Remove anodic plate.
a
b
76800
a-Rubber Plug
b-1/2 in. Bolt
c. Remove gear case from drive shaft housing.
a
b
76801
a-6 Nuts and Washers (3 Each Side)
b-Bolt (Located In Anodic Cavity)
5. Bravo Two and Diesel Bravo Two X:
a. Remove gear case from drive shaft housing.
76802
b
a
a-6 Nuts and Washers (3 Each Side)
b-Bolt
