Mercury BRAVO Service Manual

DRIVE SHAFT HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3A-45
2. Install thrust bearing and garter spring with silver side of bearing toward garter spring.
Lubricate parts with gear lube.
76848
a
b
a-Thrust Bearing (Silver Side Toward Garter Spring)
b-Garter Spring
3. Lower clutch over shaft while allowing it to turn clockwise.
22106
a
a-Clutch
4. Install top garter spring and thrust bearing with silver side of bearing toward garter
spring.
76862
a
b
a-Garter Spring (Silver Side Toward Garter Spring)
b-Thrust Bearing
