DRIVE SHAFT HOUSING

SERVICE MANUAL NUMBER 28

90-863160 MAY 2000 Page 3A-63

12. Move shift linkage to the neutral detent position as shown. Apply liberal amount of Spe-

cial Lubricant 101 to I.D. of screw recess.

76852

a-Screw Recess
