Mercury BRAVO Service Manual

BRAVO ONE GEAR HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3B-9
1-Gear Housing
2-Shims
3-Bearing Cup
4-Tapered Bearing
5-Driven Gear
6-Needle Bearing
7-Pinion Gear
8-Washer
9-Screw
10 - Propeller Shaft
11 - Washer
12 - Tapered Bearing
13 - Bearing Cup
14 - Load Ring
15 - Washer
16 - O-Ring
17 - Seals
18 - Bearing Carrier
19 - Washer
20 - Drain Screw
21 - Tab Washer
22 - Bearing Carrier Retainer
23 - Propeller Hub Assembly
24 - Washer
25 - Belleville-Washer
26 - Washer
27 - Propeller Nut
A
- Quicksilver 2-4-C Marine Lubricant with Teflon
B
- Quicksilver High Performance Gear Lube (Use on All Bearing Surfaces)
C
- Loctite 271
D
- Quicksilver Special Lubricant 101
E
- Quicksilver Engine Coupler-Spline Grease
F
- Perfect Seal
