BRAVO ONE GEAR HOUSING SERVICE MANUAL NUMBER 28
Page 3B-34 90-863160 MAY 2000
8. Temporarily install bearing carrier retaining nut to prevent damage to threads.
9. Torque pinion screw to 45 lb-ft (61 Nm).
22260
a
b
c
d
a-Drive Shaft Adaptor Tool (91-61077T)
b-Breaker Bar And Socket
c-Torque Wrench And Socket
d-Bearing Carrier Retainer
10. Remove bearing carrier retainer nut previously placed in unit for protection of threads.
11. Install upper bearing cup and tab washer.
a
b
a-Tab Washer
b-Upper Bearing Cup
