BRAVO TWO GEAR HOUSING SERVICE MANUAL NUMBER 28

Page 3C-10 90-863160 MAY 2000

7. Remove items shown.

24211

a-O-Ring

b-Thrust Ring

c-Load Ring

8. Temporarily reinstall retainer nut in gear housing to protect housing threads.

22217

a-Retainer Nut
