Mercury BRAVO

BRAVO TWO GEAR HOUSING SERVICE MANUAL NUMBER 28
Page 3C-12 90-863160 MAY 2000
11. Remove drive shaft and pinion gear.
76871
a
b
a-Drive Shaft
b-Pinion Gear
12. Remove driven gear and bearing.
22283
a
a-Driven Gear And Bearing
13. Remove drive shaft bearing cup and shims. Retain shims for reassembly.
22261
a
b
a-Drive Shaft Bearing Cup
b-Shims
