Mercury BRAVO Service Manual

SERVICE PROCEDURES REQUIRING MINOR DISASSEMBLY
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 4A-7
1-Gimbal Ring
2-Bushing
3-Bushing
4-Flat Washer
5-Hinge Pin
6-Trim Position Sender
7-Clip
8-Lockwasher
9-Screw
10 - Clip
11 - U-Bolt
12 - Plate
13 - Locknuts
14 - Swivel Shaft
15 - Flat Washer (Smaller I.D.)
16 - Flat Washer (Larger I.D.)
17 - Clamp Screw
18 - Locknut
19 - Nut
20 - Screw
21 - Clamp Plate
22 - Screws (2) (High Performance Tran-
som Only)
23 - Hinge Pin (High Performance Tran-
som Only)
24 - Magnum and High Performance Gim-
bal Ring Identification. (Filled Area)
25 - Standard Gimbal Ring Identification.
(Two Ribs)
26 - Steering Lever
A
- Resiweld Sealer
B
- Quicksilver 2-4-C Marine Lubricant with Teflon
