Mercury BRAVO

SERVICE PROCEDURES REQUIRING MAJOR DISASSEMBLY SERVICE MANUAL NUMBER 28
Page 4B-30 90-863160 MAY 2000
4. Loosen shift cable bellows crimp clamp and pull shift cable through shift cable bellows.
50458
a
b
c
a-Crimp Clamp
b-Shift Cable
c-Shift Cable Bellows
5. Remove shift cable bellows from gimbal housing.
76663
a
b
a-Shift Cable Bellow
b-Hose Clamp
6. Remove old adhesive from shift cable bellows mounting surface using lacquer thinner.
22454
a
a-Shift Cable Bellows Mounting Surface
