SERVICE PROCEDURES REQUIRING MAJOR DISASSEMBLY
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 4B-57
Crimp Clamp Tool
74148
a
a
b
b
c
a
a-Bevel Edges
b-3/4 in. Nut
c-Pliers
1. Weld a 3/4 in. nut to the jaws of a pair of pliers (as shown).
2. Saw the nut in half without damaging the pliers.
3. Clamp the jaws of the pliers in a vice so that the two halves of the nut are pressed firmly
together.
4. Use a 1/2 in. drill bit to drill the threads out of the nut.
5. Remove the pliers from the clamp and bevel the edges of the nut as indicated.
