Mercury BRAVO

To Next Page

To Previous Page

TRIM CYLINDERS

SERVICE MANUAL NUMBER 28

90-863160 MAY 2000 Page 5B-13

9. Remove small O-ring from end of piston rod.

22132

a-Small O-ring

b-Piston Rod

10. Clean all parts in solvent. Be sure all parts are dry before reassembly.
