CORROSION PROTECTION - ALL MODELS
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 7A-11
4. Guide wire through hole until wire protrudes through cavity on the bottom of exhaust
pipe.
22235
a
a
a-Wire
5. Secure ring terminals to tracer wire.
6. Guide leads through center hole in connector block.
IMPORTANT: Orange lead is approximately 6 in. (150 mm) longer than the brown lead.
7. Pull leads ALL the way into the boat.
22234
a
b
a-Wire
b-Leads
To Next Page
