REMOVAL, INSTALLATION AND ADJUSTMENTS
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 2A-7
5. Remove the locknuts holding the sterndrive onto the bell housing, then remove the
sterndrive unit.
22031
b
a
a-Locknuts (6) And Flat Washers (5)
b-Ground Plate (Flat Washer Not Used Here)
22025
d
c
c-Shift Linkage Jaws
d-Shift Cable End
6. Ensure the shift cable linkage jaws open and release the shift cable end.
To Next Page
