REMOVAL, INSTALLATION AND ADJUSTMENTS SERVICE MANUAL NUMBER 28
Page 2A-28 90-863160 MAY 2000
18. Attach the speedometer hose fitting to the sterndrive unit.
a. Raise the sterndrive unit to gain access to the area between the gimbal housing and
the sterndrive unit. Locate the opening in the forward end of the anti-ventilation plate.
b. Insert the speedometer hose fitting into the opening.
22025
b
a
a-Speedometer Hose Fitting
b-Opening
c. With the fitting fully seated, turn the handle clockwise to a tightly seated position.
22025
a
a-Speedometer Hose Fitting Installed (Handle Pointing Forward)
To Next Page
