Setting the Output Conditions
ZW-7000/5000
User's Manual
139
4
Settings for Function
Setting the Frequency Filter
Set a filter to ignore or detect the changes in a specific frequency in the measured data.
(1) List of lowpass filter cutoff frequencies [mHz]
(2) List of highpass filter cutoff frequencies [mHz]
Item Setting item Setting value Description
Frequency filter Frequency filter OFF (default value) Frequency filter is not used.
Lowpass filter:
0.040 to 23735.000
(default value: 0.040)
Ignores frequency components larger than the
spe
cif
ied cut-off frequency. (Only gradual changes
are captured.)
Highpass filter:
3.000 to 23725.000
(default value: 23725.000)
Detects frequency components smaller than the
spe
cif
ied cut-off frequency. (Sudden changes are
captured.)
Bandpass filter Detects the frequency components between the cut-
off
frequency (lower limit) and the cut-off frequency
(upper limit).
Cutoff frequency Refer to the table below. Set this item when a low pass filter or a high pass
filter is sele
cted.
Cutoff frequency
(Upper li
mit)
Set this item when a band pass filter is selected.
Cutoff frequency
(Lowe
r limit)
Sensor Controller
type
Extension fiber
cable length
Lower limit value Upper limit value Initial Value
ZW-7000@ none 1000 23725000 2000
2m 1000 23725000 2000
5m 1000 23725000
2000
10m 2000 23725000
4000
20m 3000 23725000
5000
30m 4000 23725000
7000
ZW-5000@ none 1000 5931000 1000
2m 1000 5931000 1000
5m 1000 5931000
1000
10m 1000 5931000
1000
20m 1000 5931000
2000
30m 1000 5931000
2000
Sensor Controller
type
Extension fiber
cable length
Lower limit value Upper limit value Initial Value
ZW-7000@ none 64000 23725000 64000
2m 64000 23725000 64000
5m 64000 23725000 64000
10m 102000 23725000 102000
20m 160000 23725000 160000
30m 213000 23725000 213000
