- Remove the hydraulic rod fixing screw with the
corresponding sealing gasket:
- With a 19-mm hexagonal spanner, lock hydraulic
rod rotation.
- Undo the fixing screw and collect the copper
washer.
- Remove the stem dust guard with a screwdriver.
- Remove the circlip retaining the oil seal.
Beverly 300 i.e. Suspensions
SUSP - 207
