In the event that the breather pipe is present, re-
move its elastic clip that fastens to the frame.
Undo the front fixing screw of the tank to the frame.
Undo the fixing screw of the voltage regulator and
remove it.
Remove the tank, pulling it off from the bottom.
REMOVAL OF FUEL TANK
Fit the tank, inserting it from below.
Tighten the front fixing screw of the tank to the
frame.
Locking torques (N*m)
Tank front screw - frame 8 ÷ 10.5
Beverly 300 i.e. Chassis
CHAS - 271
