Creating a Fibre Channel Port Group
1. Go to iSCSI & Fibre Channel > Fibre Channel > FC Ports .
2. Click Create Port Group.
The Create Port Group window opens.
3. Specify a group name.
Name requirements:
• Length: 1–20 characters
• Valid characters: A–Z, a–z, 0–9
4. Select one or more Fibre Channel ports.
5. Click Create.
Mapping a LUN to a Fibre Channel Port Group
1. Go to iSCSI & Fibre Channel > Fibre Channel > FC Storage .
2. Select a LUN.
3. Click Action, and then select Edit LUN Mapping.
The Edit LUN Mapping window opens.
4. Select Map to FC port group.
5. Select a Fibre Channel port group.
Tip
The default group contains all Fibre Channel ports.
6. Choose whether you want to configure LUN masking.
Option Description
Enable LUN and do not configure LUN masking Do not configure LUN masking. Any initiator that is
able to connect to a Fibre Channel port in the port
group will be able to see the LUN.
Keep LUN disabled and configure LUN masking in
the next step
Configure LUN masking. You can restrict which
initiators can see the LUN.
7. Click OK.
8. Optional: Configure LUN masking.
a. Add one or more initiator WWPNs to the LUN's authorized initiators list.
Method Steps
Add from WWPN list 1. Select one or more initiator WWPNs in the
WWPN list.
2. Click Add.
QTS 4.5.x User Guide
iSCSI & Fibre Channel 320
