R&S ZVB - Page 908

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 893
LO | LO1 – local oscillator signal no. 1
LO2 – local oscillator signal no. 2, for 2-stage mixer measurements
([SENSe<Ch>:]FREQuency:CONVersion:MIXer:STAGes)
IF – mixer output signal
*RST value
LO
SCPI,
Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFIXed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:FUNDamental RF | LO | LO1 | LO2 |
IF
Selects the mixer input or output signal which is at the channel base frequency, to be defined via
[SENSe<Ch>:]FREQuency:STARt, [SENSe<Ch>:]FREQuency:STOP,
[SENSe<Ch>:]FREQuency:CW etc..
<Ch>
Channel number
Parameters
RF – mixer input signal
LO | LO1 – local oscillator signal no. 1
LO2 – local oscillator signal no. 2, for 2-stage mixer measurements
([SENSe<Ch>:]FREQuency:CONVersion:MIXer:STAGes)
IF – mixer output signal
*RST value
RF
SCPI,
Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:IFFixed <fixed freq>
[Deprecated command, replaced by [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed]
Defines a fixed frequency and assigns it to the IF signal (for alternative commands see example below).
<Ch>
Channel number
<fixed freq>
Fixed frequency.
Range [def. unit]
Depending on the instrument model [Hz]. The increment (parameters UP or
DOWN) is 0.1 kHz.
*RST value
Minimum of the analyzer's frequency range, f
MIN
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; FREQ:CONV:MIX:IFF 1 GHz
Reset the analyzer and specify a fixed frequency of 1 GHz, to be assigned to
the IF signal.
FREQ:CONV:MIX:FFIX?; FIX?
