RL78/G1H CHAPTER 5 PORT FUNCTIONS

R01UH0575EJ0120 Rev. 1.20 Page 90 of 920

Dec 22, 2016

Table 5 - 8 Setting Examples of Registers When Using P20 to P22 Pin Function

Pin Name

Used Function

ADPC ADM2 PMxx Pxx

Function

Name

I/O

P20 P20 Input ADPC = 01H × 1 ×

Output ADPC = 01H × 0 0/1

ANI0 Analog input ADPC = 00H/02H to 0FH 00x0xx0x,

10x0xx0x

1×

AVREFP Reference voltage

input

ADPC = 00H/02H to 0FH 01x0xx0x 1 ×

P21 P21 Input ADPC = 01H/02H × 1 ×

Output ADPC = 01H/02H × 0 0/1

ANI1 Analog input ADPC = 00H/03H to 0FH xx00xx0x 1 ×

AVREFM Reference voltage

input

ADPC = 00H/03H to 0FH xx10xx0x 1 ×

P22 P22 Input ADPC = 01H to 03H × 1 ×

Output ADPC = 01H to 03H × 0 0/1

ANI2 Analog input ADPC = 00H/04H to 0FH × 1 ×
