Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 5 PORT FUNCTIONS
R01UH0575EJ0120 Rev. 1.20 Page 93 of 920
Dec 22, 2016
Table 5 - 11 Setting Examples of Registers When Using P130 to P144 Pin Function
Pin
Name
Used Function
POMxx PMCxx PMxx Pxx
Alternate Function Output
Function Name I/O
SAU Output
Function
Other than SAU
P130 P130 Output ―――0/1 ――
P137 P137 Input ―――× ――
INTP0 Input ―――× ――
P140 P140 Input ――1× ――
Output ――00/1 ― PCLBUZ0 = 0
PCLBUZ0 Output ――00 ――
INTP6 Input ――1× ――
P141 P141 Input ――1× ――
Output ――00/1 ― PCLBUZ1 = 0
PCLBUZ1 Output ――00 ――
INTP7 Input ――1× ――
P142 P142 Input × ― 1× ――
Output 0 ― 0 0/1 SCK30 = 1 ―
N-ch OD
output
1 ― 00/1
SCK30 Input × ― 1× ――
Output 0/1 ― 01 ――
P143 P143 Input × ― 1× ―
Output 0 ― 00/1 ――
N-ch OD
output
1 ― 00/1
SI30 Input × ― 1× ――
RxD3 Input × ― 1× ――
P144 P144 Input × ― 1× ――
Output 0 ― 00/1 TxD3/
SO30 = 1
―
N-ch OD
output
1 ― 00/1
SO30 Output 0/1 ― 01 ――
TxD3 Output 0/1 ― 01 ――
