RL78/G1H CHAPTER 7 TIMER ARRAY UNIT
R01UH0575EJ0120 Rev. 1.20 Page 173 of 920
Dec 22, 2016
The rules of the simultaneous channel operation function are applied in a channel group (a master channel and
slave channels forming one simultaneous channel operation function).
If two or more channel groups that do not operate in combination are specified, the basic rules of the simultaneous
channel operation function in 7.4.1 Basic rules of simultaneous channel operation function do not apply to the
channel groups.
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3)
Channel group 1
(Simultaneous channel operation
function)
* A channel that operates
independent channel operation
function may be between a master
and a slave of channel group 1.
Furthermore, the operating clock
may be set separately
CK00
Channel 0: Master
Channel 2: Slave
TAU0
Example
CK00
Channel 3: Independent channel
operation function
Channel 1: Independent channel
operation function
CK01
To Next Page
