RL78/G1H CHAPTER 7 TIMER ARRAY UNIT
R01UH0575EJ0120 Rev. 1.20 Page 198 of 920
Dec 22, 2016
Figure 7 - 46 Operation Procedure of Interval Timer/Square Wave Output Function (2/2)
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3)
Software Operation Hardware Status
TAU
stop
To hold the TOmn pin output level
Clears the TOmn bit to 0 after the value to
be held is set to the port register.
When holding the TOmn pin output level is not
necessary
Setting not required.
The TOmn pin output level is held by port function.
The TAUmEN bit of the PER0 register is cleared to 0. Input clock supply for timer array unit m is stopped
All circuits are initialized and SFR of each channel is
also initialized.
(The TOmn bit is cleared to 0 and the TOmn pin is set
to port mode.)
To Next Page
