(1) Register setting
Figure 14 - 24 Example of Contents of Registers for Master Transmission of 3-Wire Serial I/O (CSIp)
(a) Serial mode register mn (SMRmn)
(b) Serial communication operation setting register mn (SCRmn)
(c) Serial data register mn (SDRmn) (lower 8 bits: SIOp)
(d) Serial output register m (SOm)... Sets only the bits of the target channel.
(e) Serial output enable register m (SOEm)... Sets only the bits of the target channel to 1.
(f) Serial channel start register m (SSm)... Sets only the bits of the target channel to 1.
Remark : Setting is fixed in the CSI master transmission mode,
: Setting disabled (set to the initial value)
0/1: Set to 0 or 1 depending on the usage of the user
1514131211109876543210
SMRmn
CKSmn
0/1
CCSmn
0
0 0 0 0 0
STSmn
0 0
SISmn0
0 1 0 0 0
MDmn1
0
MDmn0
0/1
Operation clock (fMCK) of channel n
0: Prescaler output clock CKm0 set by the SPSm register
1: Prescaler output clock CKm1 set by the SPSm register
Interrupt source of channel n
0: Transfer end interrupt
1: Buffer empty interrupt
1514131211109876543210
SCRmn
TXEmn
1
RXEmn
0
DAPmn
0/1
CKPmn
0/1
0
EOCmn
0
PTCmn1
0
PTCmn0
0
DIRmn
0/1 0
SLCmn1
0
SLCmn0
0 0 1 1
DLSmn0
0/1
Selection of data transfer sequence
0: Inputs/outputs data with MSB first
1: Inputs/outputs data with LSB first
Setting of data length
0: 7-bit data length
1: 8-bit data length
Selection of the data and clock phase (For
details about the setting, see
14.3
Registers Controlling Serial Array Unit
.)
1514131211109876543210
SDRmn
Baud rate setting
(Operation clock (f
MCK) division setting) 0
Transmit data
(Transmit data setting)
SIOp
1514131211109876543210
SOm
0 0 0 0
CKOm3
0/1
CKOm2
0/1
CKOm1
0/1
CKOm0
0/1 0 0 0 0
SOm3
0/1
SOm2
0/1
SOm1
0/1
SOm0
0/1
Communication starts when these bits are 1 if the clock phase is
non-reversed (the CKPmn bit of the SCRmn = 0). If the clock phase is
reversed (CKPmn = 1), communication starts when these bits are 0.
1514131211109876543210
SOEm
0 0 0 0 0 0 0 0 0 0 0 0
SOEm3
0/1
SOm2
0/1
SOEm1
0/1
SOEm0
0/1
1514131211109876543210
SSm
0 0 0 0 0 0 0 0 0 0 0 0
SSm3
0/1
SSm2
0/1
SSm1
0/1
SSm0
0/1
