Conventions Data significance: Higher digits on the left and lower digits on the right
Active low representations: ×××
(overscore over pin and signal name)
Note: Footnote for item marked with Note in the text
Caution: Information requiring particular attention
Remark: Supplementary information
Numerical representations: Binary..................×××× or ××××B
Decimal...............××××
Hexadecimal .......××××H
Related Documents The related documents indicated in this publication may include preliminary versions.
However, preliminary versions are not marked as such.
Caution The related documents listed above are subject to change without notice. Be sure to use the latest
version of each document when designing.
Documents Related to Devices
Document Name Document No.
RL78/G1H User’s Manual Hardware This manual
RL78 Family User’s Manual Software R01US0015E
Documents Related to Flash Memory Programming (User’s Manual)
Document Name Document No.
PG-FP5 Flash Memory Programmer User’s Manual ―
RL78, 78K, V850, RX100, RX200, RX600 (Except RX64x), R8C, SH R20UT2923E
Common R20UT2922E
Setup Manual R20UT0930E
