RL78/G1H CHAPTER 15 SERIAL INTERFACE IICA

R01UH0575EJ0120 Rev. 1.20 Page 484 of 920

Dec 22, 2016

(i) When WTIMn = 0 (after restart, does not match address (= extension code))

(ii) When WTIMn = 1 (after restart, does not match address (= extension code))

Remark n = 0, 1

ST AD6 to AD0 D7 to D0R/W ACK ACK SPST AD6 to AD0 D7 to D0R/W ACK ACK

5 1 2 3 4

▲1: IICSn = 0001×110B

▲2: IICSn = 0001×000B

▲3: IICSn = 0010×010B

▲4: IICSn = 0010×000B

5: IICSn = 00000001B

Remark ▲: Always generated

: Generated only when SPIEn = 1

× : Don’t care

ST AD6 to AD0 D7 to D0R/W ACK ACK SPST AD6 to AD0 D7 to D0R/W ACK ACK

6 1 2 3 4 5

▲1: IICSn = 0001×110B

▲2: IICSn = 0001××00B

▲3: IICSn = 0010×010B

▲4: IICSn = 0010×110B

▲5: IICSn = 0010××00B

6: IICSn = 00000001B

Remark ▲: Always generated

: Generated only when SPIEn = 1

× : Don’t care
