RL78/G1H CHAPTER 15 SERIAL INTERFACE IICA

R01UH0575EJ0120 Rev. 1.20 Page 485 of 920

Dec 22, 2016

(d) Start ~ Address ~ Data ~ Start ~ Address ~ Data ~ Stop

(i) When WTIMn = 0 (after restart, does not match address (= not extension code))

(ii) When WTIMn = 1 (after restart, does not match address (= not extension code))

Remark n = 0, 1

ST AD6 to AD0 D7 to D0R/W ACK ACK SPST AD6 to AD0 D7 to D0R/W ACK ACK

4 1 2 3

▲1: IICSn = 0001×110B

▲2: IICSn = 0001×000B

▲3: IICSn = 00000110B

4: IICSn = 00000001B

Remark ▲: Always generated

: Generated only when SPIEn = 1

× : Don’t care

ST AD6 to AD0 D7 to D0R/W ACK ACK SPST AD6 to AD0 D7 to D0R/W ACK ACK

4 1 2 3

▲1: IICSn = 0001×110B

▲2: IICSn = 0001××00B

▲3: IICSn = 00000110B

4: IICSn = 00000001B

Remark ▲: Always generated

: Generated only when SPIEn = 1

× : Don’t care
