RL78/G1H CHAPTER 15 SERIAL INTERFACE IICA

R01UH0575EJ0120 Rev. 1.20 Page 497 of 920

Dec 22, 2016

(g) When arbitration loss occurs due to a stop condition when attempting to generate a restart condition

(i) When WTIMn = 0

(ii) When WTIMn = 1

Remark n = 0, 1

ST AD6 to AD0 D7 to D0R/W ACK ACK SP

STTn = 1

↓

4 1 2 3

▲1: IICSn = 1000×110B

▲2: IICSn = 1000×000B (Sets the WTIMn bit to 1)

▲3: IICSn = 1000××00B (Sets the STTn bit to 1)

4: IICSn = 01000001B

Remark ▲: Always generated

: Generated only when SPIEn = 1

× : Don’t care

ST AD6 to AD0 D7 to D0R/W ACK ACK SP

STTn = 1

↓

3 1 2

▲1: IICSn = 1000×110B

▲2: IICSn = 1000××00B (Sets the STTn bit to 1)

3: IICSn = 01000001B

Remark ▲: Always generated

: Generated only when SPIEn = 1

× : Don’t care
