Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 558 of 920
Dec 22, 2016
Table 18 - 6 Baseband Function Controlling Register (2/2)
No. Register name Symbol Address Reset value
(40) CSMA-CA start count register CSMASTACOUNT 004FH, 004EH 000EH
(41) Communication status register 1 COMSTATE1 0066H 00H
(42) Communication status register 2 COMSTATE2 0067H 00H
(43) Estimate control register BBEVAREG 0068H 00H
(44) Back off period register 2 BBBOFFPROD2 0069H 00H
(45) Communication status register 3 COMSTATE3 006FH 00H
(46) ACK receive wait time setting register ACKRCVWIT 0071H, 0070H 0300H
(47) Retransmission start compare register RETRNWUP 0073H, 0072H 0004H
(48) ANTSW output timing setting register BBANTSWTIMG 007BH, 007AH 0072H
(49) Receive frame length register BBRXFLEN 00A1H, 00A0H 0000H
(50) Receive data counter register BBRXCOUNT 00A3H, 00A2H 0000H
(51) Transmit frame length register BBTXFLEN 00A5H, 00A4H 0000H
(52) Preamble length setting register BBPAMBL 00A7H, 00A6H 0004H
(53) Frequency setting register BBFREQ 00ABH-00A8H 36FC3BA0H
(54) Symbol rate setting register BBSYMBLRATE 00AEH-00ACH 0000F0
(55) SUBG control register BBSUBGCON 00B0H 0CH
(56) Modulation method setting register BBMODSET 00B1H 42H
(57) CCA time register CCATIME 00B3H, 00B2H 000DH
(58) Antenna diversity mode register BBANTDIV 00B4H 30H
(59) Mode switch frame transmit register BBTXMODESW 00B9H, 00B8H 0000H
(60) Mode switch frame receive register BBRXMODESW 00BBH, 00BAH 0000H
(61) Transmit data counter register BBTXCOUNT 00BDH, 00BCH 0000H
(62) PHY header receive register BBPHRRX 00BEH 00H
(63) Preamble setting register BBPABL 00C1H, 00C0H 00AAH
(64) SFD setting register BBSFD 00C5H-00C2H 00007209H
(65) SHR control register BBSHRCON 00C6H 02H
(66) ANT0 read register BBANT0RD 00C9H, 00C8H 0100H
(67) ANT1 read register BBANT1RD 00CBH, 00CAH 0100H
(68) Antenna switch time register BBANTDIVTIM 00CFH, 00CEH 000AH
(69) Receive start timeout setting register BBANTTIMOUT 00D1H, 00D0H 0100H
(70) Number-of-receive-byte interrupt compare register BBRCVINTCOMP 00D3H, 00D2H 0010H
(71) Back off period total number register BBBOPTOTAL 00D5H, 00D4H 0000H
(72) CCA total number BBCCATOTAL 00D6H 00H
(73) RF Initial setting register0 RFINI00-RFINI02 00D8H - 00DAH XXH
(74) RF Initial setting register1 RFINI10-RFINI12 00DCH - 00DEH XXH
(75) PAN identifier register 1 BBPANID1 00E1H, 00E0H FFFFH
(76) Short address register 1 BBSHORTAD1 00E3H, 00E2H FFFFH
(77) Extended address register 1 BBEXTENDAD13 00EBH, 00EAH 0000H
BBEXTENDAD12 00E9H, 00E8H 0000H
BBEXTENDAD11 00E7H, 00E6H 0000H
BBEXTENDAD10 00E5H, 00E4H 0000H
(78) Receive timeout register BBTIMEOUT 00EDH, 00ECH 07D0H
(79) ANTSW control register ANTSWCON 0080H 00H
(80) Clock output control register CLKOUTCON 0081H 00H
(81) Port direction register GPIODIR 0082H 00H
(82) Port data register GPIODATA 0083H 00H
(83) SFD status register 2 BBSFD2 0103H-0100H XXXXXXXXH
(84) SFD status register 3 BBSFD3 0107H-0104H XXXXXXXXH
(85) SFD status register 4 BBSFD4 010BH-0108H XXXXXXXXH
(86) FEC setting register BBFECCON 010CH 00H
(87) Address filter extended address setting register BBADFCON 010DH 00H
(88) Antenna diversity mode register2 BBANTDIV2 010EH 00H
(89) Lower limit threshold setting register after SFD detection PWRLOWTH2 050FH 00H
