(1) RF start register (BBRFCON)
Enables the RF function by setting 1 to the RF function enable bit.
Releases the analog circuit reset by setting 1 to the analog reset release bit.
The BBRFCON register consists of 8 bits and can be accessed (serial interface communication) in 8 bit unit.
Reset signal generation sets this register to 01H.
Figure 18 - 7 RF Start Register (BBRFCON) Format
Caution Be sure to clear bits 2 to 7 to “0”.
Address: 0000H After reset: 01H R/W
Symbol76543210
BBRFCON 000000ANARESETB RFSTART
ANARESETB Analog reset release bit
0 Analog circuit reset status
1 Analog circuit reset release
RFSTART RF function enable bit
0 RF function disabled
1 RF function enabled
