Figure 18 - 9 Transmit/Receive Mode Register 0 (BBTXRXMODE0) Format
Caution Be sure to clear bit 1 to “0”.
Address:
0002H
After reset:
00H
R/W
Symbol76543210
BBTXRX
MODE0
INTRAPANEN BEACON BATLIFEEXT AUTORCV1 AUTORCV0 AUTOACKEN 0 CCATYPE0
INTRAPANEN intraPAN enable bit
0 intraPAN disabled
1 intraPAN enabled
BEACON BEACON mode bit
0 Non-beacon mode
1 BEACON mode
BATLIFEEXT Battery life extension mode bit
0 Battery life extension mode disabled
1 Battery life extension mode enabled
AUTORCV1 Automatic receive switch mode 1 enable bit (Receive
→
Receive)
0 Auto receive switch function disabled
1 Auto receive switch function enabled
AUTORCV0 Automatic receive switch mode 0 enable bit (Transmit
→
Receive)
0 Auto receive switch function disabled
1 Auto receive switch function enabled
AUTOACKEN Automatic ACK mode enable bit
0 Automatic ACK disabled
1 Automatic ACK enabled
CCATYPE0 CCA type bit
0Normal
1CCA/ED
