RL78/G1H CHAPTER 18 RF TRANSCEIVER

R01UH0575EJ0120 Rev. 1.20 Page 564 of 920

Dec 22, 2016

Figure 18 - 10 Transmit/Receive Mode Register 1 (BBTXRXMODE1) Format

Caution Be sure to clear bits 1 and 2 to “0”.

Address:

0003H

After reset: C0H R/W

Symbol76543210

BBTXRX

MODE1

ACKRCVPOI

SQCNUMSU

PEN

ACKFV1 ACKFV0 ACKFVEN 0 0 CCASEL

ACKRCVPOI

ACK receive point setting bit

0 Upon completion of the receive

1 Upon reception of the PHR

SQCNUMSU

PEN

Sequence number suppress bit

0 Sequence number suppress enabled

1 Sequence number suppress disabled

ACKFV1 ACK reply frame version setting bit 1

0 Frame version bit 13 = 0

1 Frame version bit 13 = 1

ACKFV0 ACK reply frame version setting bit 0

0 Frame version bit 12 = 0

1 Frame version bit 12 = 1

ACKFVEN ACK reply frame version setting enable bit

0 Version value of the receive frame

1 Values of the ACK reply frame version setting bits 0 and 1

CCASEL CCA result select bit

0CCA/ED

1 RSSI
