RL78/G1H CHAPTER 18 RF TRANSCEIVER

R01UH0575EJ0120 Rev. 1.20 Page 570 of 920

Dec 22, 2016

(6) Enhanced-ACK mode register (BBEACKMODE)

This register sets the enhanced ACK mode.

The BBEACKMODE register consists of 8 bits and can be accessed (serial interface communication) in 8 bit

unit.

Reset signal generation sets this register to 01H.

Figure 18 - 12 Enhanced ACK Mode Register (BBEACKMODE) Format

Caution Be sure to clear bits 1 to 7 to “0”.

Address:

0006H

After reset: 01H R/W

Symbol76543210

BBEACK

MODE

0000000ENHACK

MODEBIT

ENHACK

MODEBIT

Enhanced ACK Mode bit

0 Enhanced ACK Mode function disabled

1 Enhanced ACK Mode
