RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 586 of 920
Dec 22, 2016
(20) Extended address register 0 (BBEXTENDAD00 to BBEXTENDAD03)
These registers are used to set the extended address of the first address filter. They consist of 64 bits (16 bit
timed by 4) and are used to detect the match with a received extended address.
The BBEXTENDAD00 to BBEXTENDAD03 registers are set by the serial interface in 8-bit units.
Reset signal generation clears these registers to 0000H.
Figure 18 - 26 Extended Address Register 0 (BBEXTENDAD00 to BBEXTENDAD03) Format
Address:
001FH, 001EH
After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD03
76543210
BBEXTENDAD03 Extended address bits 63 to 48
Address:
001DH, 001CH
After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD02
76543210
BBEXTENDAD02 Extended address bits 47 to 32
Address:
001BH, 001AH
After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD01
76543210
BBEXTENDAD01 Extended address bits 31 to 16
Address:
0019H, 0018H
After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD00
76543210
BBEXTENDAD00 Extended address bits 15 to 0
